Optimizing the Use of CNC Coolant-Considerations for CNC Coolant
Find the Right Coolant Concentration
Insufficient coolant concentration can lead to some problems, including bacterial development, shorter tool lives, and corrosion of the machine and workpiece.
However, if the coolant concentration is too high, you can notice any of the following:
Foaming
Fewer lubricants
Discarded coolant
Reduced tool life due to residue formation
Machine and machined component stains
Toxicity
At the beginning of each day, machinists should check the coolant and maintain a suitable level of focus. Hand refractometers are great for controlling and monitoring cutting fluid amounts. Keep in mind that evaporation, splashing, and misting can cause machine coolant concentrations to fluctuate by up to 20% every day. To understand how the coolant system functions and how much the concentration levels vary from day to day; it is necessary to keep a daily diary of concentration levels for each CNC machine.
To increase the lifespan of the coolant, the cutting tools, and your CNC machine, it's critical to choose the right coolant for your machine and the metals you're machining and to maintain the specified concentration levels.
CNC Coolant Concentration Chart
Below is a coolant concentration chart containing variations in the CNC coolant concentration levels:
Material |
Milling |
Drilling |
Tapping |
Turning |
Aluminum |
Soluble oil (96% water) or mineral oil |
Soluble oil (70-90% water) |
25% sulfur-based oil mixed with mineral oil |
Mineral oil with 10% fat (or) soluble oil |
Brass |
Soluble oil (96% water) |
Soluble oil |
10-20% lard oil with mineral oil |
Mineral oil with 10% fat |
Bronze |
Soluble oil |
Soluble oil |
30% lard with mineral oil |
Soluble oil |
Alloy Steels |
10% lard oil with 90% mineral oil |
Soluble oil |
30% lard oil with 70% mineral oil |
25% sulfur base oil with 75% mineral oil |
Cast Iron |
Dry |
Dry |
Dry or 25% lard oil with 80% mineral oil |
Dry |
Malleable Iron |
Soluble oil |
Soluble oil |
Soluble oil |
Soluble oil |
Copper |
Soluble oil |
Soluble oil |
Soluble oil |
Soluble oil |
Low Carbon and Tool Steels |
Soluble oil |
Soluble oil |
25-40% lard oil with mineral oil |
25% lard oil with 75% mineral oil |
Change the coolant in CNC machine
The interval for changing CNC machine coolant can vary depending on factors such as the machined material, coolant type, and operating conditions of the CNC machine. However, as a general rule of thumb, most CNC machine manufacturers recommend changing the coolant every 6-12 months.
Eliminate bacteria in CNC machining coolant
Bacterial growth in CNC machining coolant can be prevented or stopped by injecting ozone directly into the coolant. Ozone effectively kills viruses, bacteria, molds, and eliminates odors in the coolant sump.
Foaming in CNC coolant
Foaming in CNC coolant is primarily caused by the lack of minerals in the water supply. It's advisable to check the water hardness using Hardness Testing Sticks to address this issue.
Conclusion
CNC machine coolants play a vital role in achieving optimal efficiency in a CNC shop by reducing heat build-up, lubricating cutting tools, and preventing discoloration and failure in various machining processes such as CNC milling, turning, or drilling. If you require assistance in determining the ideal lubricant type for your CNC machines, do not hesitate to reach out to us at STS. Our team of professionals is always ready to help.
